Material:

• Extruded aluminum

• Steel

Feature:

• 2 deflection cores allow for complete air control in both planes and equal air distribution over entire register face

• Blades are fixed by wires and are adjustable from 0 to 180 degrees

• Individual adjustable blade allows effective air control for any desired pattern in a two planes

• Opposite blade damper can be easily adjustable from the face of the grille

• Matching returns with 0 degree or 45 degree fixed deflecting blades are available

• Recommended for high sidewall, soft-fit and duct mounting

• Corrosion resistance and light weight

Specification:

• Flange: 13mm, 19mm, 25mm, 32mm (standard), and 50mm

• Blade: Adjustable

• Neck height: 50mm

• Removable core available

• All sizes can be produced upon request

• Powder coating; various colors are available

Accessories:

• Opposite blade damper
