Material:

• Extruded aluminum

• Steel

Feature:

• Designed for surface mounting in plaster or other ceiling material where a flat, overlapping border is required

• The diffuser delivers supply air in a true 360 degree radial horizontal air pattern

• Inner cone sub-assembly features a special lock arrangement for fast, easy installation and removable without special tools

• Made in all rectangular shapes for 1,2,3, and 4 way blows to accommodate rooms of irregular shape

• Excellent performance with VAV applications

• Removable core is standard for maintenance purpose

Specification:

• Flange: 32mm

• Neck Height: 50mm

• Minimum size is 300mm x 300mm

• Powder coating; various colors are available

Accessories:

• Opposite blade damper
